01018OS1CCD215T, AC Mtr, ODP, CCW Rotation Viewed from Shaft End - Non Reversible, Compressor Duty, 1 PH, 10 HP, 7.5 kW, 1800 RPM, 215T NEMA, Single-Phase – Footed, 208-230V, 47.5-43 FLA
WEG AC Motor, Rolled Steel Frame, ODP, CCW Rotation Viewed from Shaft End - Non Reversible, Compressor Duty, 1 PH, 10 HP, 7.5 kW, 1800 RPM, 215T NEMA Frame, Single-Phase – Foot Mount, 1.15 Service Factor, 208-230V, 47.5-43 FLA, 60 Hz. **Must Ship LTL Truck Freight**
*Images are for illustrative purposes and may not represent the actual configuration of the product.
Must Ship LTL Truck Freight
01018OS1CCD215T, AC Mtr, ODP, CCW Rotation Viewed from Shaft End - Non Reversible, Compressor Duty, 1 PH, 10 HP, 7.5 kW, 1800 RPM, 215T NEMA, Single-Phase – Footed, 208-230V, 47.5-43 FLA
WEG AC Motor, Rolled Steel Frame, ODP, CCW Rotation Viewed from Shaft End - Non Reversible, Compressor Duty, 1 PH, 10 HP, 7.5 kW, 1800 RPM, 215T NEMA Frame, Single-Phase – Foot Mount, 1.15 Service Factor, 208-230V, 47.5-43 FLA, 60 Hz. **Must Ship LTL Truck Freight**
*Images are for illustrative purposes and may not represent the actual configuration of the product.
Must Ship LTL Truck FreightSpecifications
WEG AC Motor, Rolled Steel Frame, ODP, CCW Rotation Viewed from Shaft End - Non Reversible, Compressor Duty, 1 PH, 10 HP, 7.5 kW, 1800 RPM, 215T NEMA Frame, Single-Phase – Foot Mount, 1.15 Service Factor, 208-230V, 47.5-43 FLA, 60 Hz. **Must Ship LTL Truck Freight**
*Images are for illustrative purposes and may not represent the actual configuration of the product.
- Class B insulation
- Start capacitor
- Ball bearings
- Manual reset thermal overload protection
- High starting torque
- Rolled steel frames have base seam welded to the frame for heavy duty use
Specifications
| Phase | Single Phase |
| Frame | 215T |
| Output | 10 HP |
| Poles | 04 |
| Frequency | 60 Hz |
| Rated speed | 1720 rpm |
| Slip | 4.44 % |
| Full Voltage - No Cables | 208-230 V |
| Rated Current | 44.2-40.0 A |
| LR Amperes | 274-248 A |
| LRC | 6.2x(Code G) |
| No Load Current | 5.20-5.80 A |
| Rated Torque | 30.5 ft.lb |
| Locked Rotor Torque | 280 % |
| Breakdown Torque | 210 % |
| Insulation Class | F |
| Service Factor | 1.15 |
| Moment of Inertia | - |
| Design | - |
| Locked Rotor Time | 10s (cold) 6s (hot) |
| Temperature Rise | 80 K |
| Duty Cycle | S1 |
| Maximum Room Temperature | 40 °C |
| Minimum Room Temperature | -20 °C |
| Degree of Protection | IP21 |
| Altitude | 1000 m |
| Cooling Method | ODP Open Drip Proof Open Motor |
| Mounting | F-1 |
| Rotation Direction | Counter Clockwise |
| Noise Level | - |
| Starting Method | Direct |
| Enclosure Material | Steel Plate |
| Front Bearing Shielding | ZZ |
| Front Bearing Size | 6208 |
| Front Bearing Type | Ball |
| Front Sealing Type | No Sealing |
| Rear Bearing Shielding | ZZ |
| Rear Bearing Size | 6206 |
| Rear Bearing Type | Ball |
| Rear Sealing Type | No Rear Sealing |
| Grease Type | Mobil Polyrex EM |
| VFD Turndown VT | N/A |
| VFD Turndown CT | N/A |
