FMD16-DS24V-0-10PK, Monoblock LED Indicator, 22mm, 24V AC/AC
FMD16-DS24V-0-10PK, Monoblock LED Indicator, 22mm, 24V AC/AC
Chint Monoblock LED Indicator, 22mm, non-metallic, 24V AC/DC, White. Box of 10.
Item: FMD16-DS24V-0-10PK
Weight: 0.5 lbs.
Made in: China
$67.70
In Stock
SKU:FMD16-DS24V-0-10PK
Specifications
Related Items
Resources
Specifications
Chint Monoblock LED Indicator, 22mm, non-metallic, 24V AC/DC, White. Box of 10.
- 22mm plastic body
- IP65 protection
- Super-bright LED illumination
- UL recognised, CE approved
ELECTRICAL SPECIFICATIONS
| Standards | IEC/EN60947-5-1, UL508 |
| Operational Voltage | 12-220 VAC/DC, 110-220VAC |
| Operational Current | le ≤ 20mA |
| Operational Humidity | 45% - 85% (No condensation) |
| Degree of Protection | IP65 |
| Service Life | ≥30000 hrs |
| Brightness | ≥ 60 cd/m2 |
| Ambient Temperature | 23° to 104°F (-5° to 40°C); average temp during 24 hrs couldn't exceed 95°F (35°C) |
