FMX USB Communication Interface, B/A female connection, 5 VAC/DC, 1.8A,, UL Type (NEMA) 1, 2, 3R, 4, 4X, 12
Item: PD22-USBBA
Made in: Italy
$32.55
In Stock
SKU:PD22-USBBA
Specifications
Related Items
Resources FMX USB Communication Interface, B/A female connection, 5 VAC/DC, 1.8A,, UL Type (NEMA) 1, 2, 3R, 4, 4X, 12
GENERAL SPECIFICATIONS
| Rated insulation voltage | 5VAC/DC |
| Interface mechanical endurance | ≤750 insertions |
| Mounting Hole Requirements | Ø22mm/Ø0.87” (Tmax = 2.3Nm/1.69lbft) |
| Transmission characteristics | 5Gbps (625MB/sec) |
| Rated current | 1.8A |
| Insulation resistance | ≤100MOhm |
| Contact resistance | ≤30mOhm |
| USB connector class | 3.0 |
| (backward compatible with USB class 2.0) | |
| Ambient Conditions | Operating temperature: -13° to 158°F (-25...+70°C) Storage temperature: -40° to 185°F (-40...+85°C) |
| Degree of protection | UL: Type 1, 2, 3R, 4, 4X 12, 12K on front(with cap mounted) |
| Materials | Polyamide |
| Certifications and compliance | Certifications obtained: cULus, EAC, CCC (pending) RINA (pending). Compliant with standards: IEC/EN 60947-1 IEC/EN 60947-5-1, UL508, CSA C22.2 n° 14. |
